EDMO

Think Jacks, Think EDMO

EDMO JS20
EDMO JS20 - Image 2
EDMO JS20 - Image 3

EDMO JS20

WLL 200,000kgs

$0.00

The EDMO JS20 Adjustable Support Stands are designed for supporting vehicles during maintenance and repairs.

Height Adjustments are in increments of 51mm, made by a hand pump which raises the inner cylinder.

Category: Tag:

Description

Working Load Limit: 200,000kgs
Closed height with load cap: 1000mm
Raised height with load cap: 1550mm
Maximum operating height with standard base: 2000mm
Estimated Weight: 400kgs each


Additional Information:

Supplied with Concave Load Cap

This is not a jack intended to lift any load.

PLEASE ENQUIRE TO WORK WITH OUR ENGINEERS TO CREATE CUSTOM LOAD CAPS, EXTENSIONS, ENGAGEMENTS AND ACCESSORIES TO SUIT YOUR SPECIFIC REQUIREMENTS.

LOAD CAPS AND EXTENSIONS ARE TO BE USED UNDER AN ADVISORY STANDARDS CODE OF PRACTICE, IN CONJUNCTION WITH SITE SAFE OPERATING PROCEDURES/RISK ASSESSMENT.

Packed on half pallet for Australian market and on skid for exportation. For more packing options, long distance and export requirements, please enquire.

Product Resources

EDMO JS20 Spec Sheet

Accessories

Accessories that are compatible with this product:

Extensions

PART No. DESCRIPTION
JS2095654-250 250mm extension

EDMO Stand Forklift Attachment

For those situations when it is easier to transport the stand via vehicle, possibly due to rough terrain or distance to travel around the workshop or site.

The fork attachment is fitted to the forklift tines and secured by a chain around the backrest.

The stand socket will then take the spigot on the fork attachment.

Working Load Limit: 1000kgs
Weight: 160kgs
Suitable for: JS2, JS5, JS10, JS15, JS20 & KS50 stands

Lead time: 8 weeks from receipt of deposit
