|Working Load Limit 1st stage:||55,000kgs|
|Working Load Limit 2nd stage:||25,000kgs|
|Closed height with load cap:||250mm|
|Raised height 1st stage:||378mm|
|Raised height 2nd stage:||490mm|
|Load Cap Supplied with Jack|
|Concave Load Cap|
|Air Supply Required:||110PSI|
|Lead time:||12 weeks from receipt of deposit|
PLEASE ENQUIRE TO WORK WITH OUR ENGINEERS TO CREATE CUSTOM LOAD CAPS, EXTENSIONS, ENGAGEMENTS AND ACCESSORIES TO SUIT YOUR SPECIFIC REQUIREMENTS.
LOAD CAPS AND EXTENSIONS ARE TO BE USED UNDER AN ADVISORY STANDARDS CODE OF PRACTICE, IN CONJUNCTION WITH SITE SAFE OPERATING PROCEDURES/RISK ASSESSMENT.
Packed on half pallet for Australian market and on skid for exportation. For more packing options, long distance and export requirements, please enquire.
